DD TECH SHUTIT BADASS HALF BOLT-ON HINGE

D&D Shut It® BadAss™ Half Bolt-On Hinge

Indent order, Average dispatch time ~ 22 days.

All bolt-on gate hinges from D&D Shut It® BadAss™ are CNC machined to the tightest tolerances in the industry. The D&D Shut It® BadAss™ Half Bolt-On Hinge is a steel bolt-on gate hinge that is designed to be used on applications where welding the hinges to the gate and end post is not an option (no field welder), therefore the only option left is to bolt them on. The D&D Shut It® BadAss™ Half Bolt-On Hinge produce near frictionless movement with maintenance free usage.

Features

• Steel body
• Steel yoke
• Designed to bolt on to an end post
• Two sealed maintenance-free bearings
• Adjustable barrel for precise installations
• Flat, bolt-on bracket for through bolting
• Zinc plated
• Load rating per gate 900kg
• Maximum gate weight 450kg
• Supplied in trade pack - 1 each

Specifications

• Gate Application: Pedestrian Gate, Driveway Gate - Double, Driveway Gate - Single, Pet Gate, Playground Gate, Public/Commercial Gate, Automated/Electric Gate, Security Gate, Privacy Gate
• Gate Type: Non Self-Closing
• Gate Material: Steel/Ornamental Iron
• Approximate Gate Height: 2000mm
• Approximate Gate Width: 3000mm
• Gate Frame/Post Shape: Square-to-Square, Square-to-Round
• Minimum Post Size: 38mm+
• Ideal Gate Gap: 67mm to 80mm
• Fixing Method: Bolt-On, Weld-On

Finish
Zinc
