DD TECH SHUTIT BADASS HEAVY DUTY HINGE

Indent item Average dispatch time ~ 22 days

D&D Shut It® BadAss™ Heavy Duty hinge

The D&D SHUT IT® Heavy-Duty BadAss Hinge is one mighty dude! Designed for the rarest of installations where even The D&D SHUT IT® ORIGINAL is not BAD enough. For these situations, D&D SHUT IT® has designed the HD to hold 50 percent more load than the D&D SHUT IT® ORIGINAL. As with all our BadAss hinges, the HD is CNC machined to the industry’s tightest tolerances.

Unique Stover Locknut™
an innovative, shaped threads provide a vibration-resistant friction fit so nut stays firm. The top thread section is deformed to create two or three locking zones (can be re-used 2-3 times). The all-metal locknuts withstand higher temperatures than nylon-insert locknuts.

High Temperature Sealed Bearings
Safe to powder-coat with hinges installed on the gate (excluding CI3850 self-closing hinge and CI3800 Stainless Steel BadAss). No greasing, no maintenance; hinge options include 1, 2, 3 or 4 bearings and performs better than roller cages that require periodic greasing.

Features

• Three sealed maintenance free bearings
• High temp[ bearings sfe to powdercoat
• Adjustable bracket for perfect installations
• Ideal for square or round-post installations
• Holds 50% more load than the Original
• Load rating per gate:1,360kg (3,000 lbs)
• Maximum gate weight: 680kg (1,500 lbs)
• Steel bracket and body
• Hinge weight 1.6kg
• Supplied in trade pack - 1 each

Specifications

• Gate Application: Pedestrian Gate, Driveway Gate - Double, Driveway Gate - Single, Pet Gate, Playground Gate, Public/Commercial Gate, Automated/Electric Gate, Security Gate, Privacy Gate
• Gate Type: Non Self-Closing
• Gate Material: Steel or Ornamental Iron
• Approximate Gate Width 2000mm
• Approximate Gate Height 3000mm
• Gate Frame/Post Shape: Square-to-Square, Square-to-Round
• Minimum Post Size: 38mm+
• Ideal Gate Gap: 61mm to 74mm
• Fixing Method: Weld-On

Finish
Zinc
